1.lpg truck: Liquid Petroleum Gas, Propane, Butane, Liquid Ammonia, etc.
2.Available tank sizes of LPG storage tank: 5m³~200m³, 2.5ton~100tons.
3.Tank Design Standard : GB-150, ASME VIII Division I U STAMP, CCC, ISO9001 : 2008.
4.Tank Testing: 100% Radiaographic Test, Magnetic Power Test, Water Pressure.
5. Optional for lpg gas plant equipments: LPG pump and motor, LPG compressor, volume flow meter, filling scales and lpg dispenser,ball valves,check valves,non-return valves,glass valve,strainer,by-pass valve and so on.
| Specification of Truck Chassis | |
| Chassis Model | ZZ1047D3815C145 |
| Driving Model | 4 X 2 |
| Cab | HOWO, 2080 cabin. |
| Left or Right Hand Drlving | |
| with air conditioner | |
| Wheel Base | 3800mm |
| Axle Loading (front/rear) | 2700/7200 kg |
| External Dimensions (L × W × H) | 5950X2350X2650mm |
| Max. driving speed | 95 km/h |
| Engine - Model | Yuchai engine, YN4102QBZL |
| Engine - Type | 4-cylinders in a line, turbo-charging and inter-cooling |
| Engine - Horse Power | 116Hp |
| Engine - Max output power | 85 kW |
| Engine - Emission standard | Euro 2 |
| Engine - Displacement | 3.76 L |
| Engine - Min. Fuel consumption at full load | ≤217 g/kw.h |
| Gearbox | Manual type, WLY6TS55C, 6 forwards & 1 reverse |
| Clutch | Reinforced diaphragm clutch |
| Tire | 7.50R16, 6 pieces with 1 spare tire. |
| Fuel box | 120L /steel material |
| LPG tank | |
| Filling Medium | Liquefied Petroleum Gas |
| Working temperature | -40~50 °C |
| Volume: | 5,000Liters |
| Tank material: | Q345R |
| Tank diameter: | 1600mm |
| Tank thickness: | 10mm |
| End plate thickness: | 10mm |
| Tank length: | As designed |
| Gas phase | Flange type,DN50/2" or according to customer request |
| Liquid Phase | Flange type,DN50/2" or according to customer request |
| Filling gas | Propane(LPG) |
| Working Pressure: | 1.61Mpa |
| Design Pressure | 1.71 Mpa |
| Testing pressure | 2.21Mpa |
| Corrosion Allowance | 1.0 mm |
| Refilling Accessory | |
| Directly driven by PTO(easy for future maintenance) | - |
| LPG Pump | Chinese brand CLW 15-5 |
| Inlet 2" NPT and Outlet 2" NPT | |
| Flow rate :15.5 m3/h | |
| 780 r/min for rotation speed | |
| LPG Flow meter | TSC-50 model |
| Showing filling volume | |
| Inlet/Outlet 2"/DN50 | |
| Maximum Capacity:76~380lpm | |
| With Mechanical Register, strainer, air eliminator, Diff. Valve and Back Check Valve | |
| with Ticket Printer. | |
| LPG dispenser | English remarks with printer for receipt |
| Chinese top brand-JINGDA | |
| For measuring filling weight from truck to cylinders | |
| offer receipt to clients | |
| Designed at back of truck | |
| 4 meters refilling hose | |
| Filling hose | 15M,retractable with REGO adapter for small tank refilling |
| Level Gauge | Rochester level gauge or Chinese brand |
| Safety Valve - Model No. | A412F-25-16 |
| Safety Valve - Type | Built-in |
| Safety Valve - Nominal Pressure | 2.5 Mpa |
| Safety return valve | 1 PC |
| Pipeline safety valve | 1 PC |
| Equipment and Valve Box | Located at side of LPG bobtail (opposite driver's side) |
| Strong design with rolling off cabinet | |
| Manhole | DN450 |
| Thermometer | 1 pc, WTQ-280 |
| Pressure Gauge | 2 pc, YN-100T |
| Emergency shut off Valve | 2 pcs with switch inside valve box and at rear of truck |
| Fender | Steel |
